FBR-6 ROOF CONVEYOR
All Fiberglass Frame
This conveyor is more flexible and forgiving than metal conveyors. It will “spring back” upon impact in most cases rather than bend or dent.
Fiberglass doesn’t rust. This greatly reduces the cost and time involved to repair metal fatigue or rust.
CONVEYOR SPECIFICATIONS
FBR-6-26
| Conveyor length | 26 Feet |
| Weight | 1100 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 26 Feet |
FBR-6-31
| Conveyor length | 31 Feet |
| Weight | 1200 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 31 Feet |
FBR-6-36
| Conveyor length | 36 Feet |
| Weight | 1300 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 36 Feet |
FBR-6-38
| Conveyor length | 26 Feet |
| Weight | 1400 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 Inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 38 Feet |
FBR-6-40
| Conveyor length | 40 Feet |
| Weight | 1500 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 40 Feet |
FBR-6-41
| Conveyor length | 41 Feet |
| Weight | 1550 lbs. |
| Belt Speed | 60 ft per minute |
| Cleat | 3-3/4″ Tall double cleat |
| Cleat Spacing | 90 inch centers |
| Max Incline Angle | 70 degrees |
| Max Discharge Height | 41 Feet |
MANUALS AND DOWNLOADS
Downloads
Manual Sections
RTH SERIES TURNTABLES
RTH-3000
| Max Bed Clearance | 60 inches |
| Weight | 1196 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 26′-36′ |
Hydraulic Turntable Functions
- Post lifts up for 5 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
RTH-3000
| Max Bed Clearance | 60 inches |
| Weight | 1386 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 38′-41′ |
Hydraulic Turntable Functions
- Post lifts up for 5 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
RTH-4000
| Max Bed Clearance | 72 inches |
| Weight | 1224 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 26′-36′ |
Hydraulic Turntable Functions
- Post lifts up for 6 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
HDRTH-4000
| Max Bed Clearance | 72 inches |
| Weight | 1196 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 38′-41′ |
Hydraulic Turntable Functions
- Post lifts up for 6 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
RTH-6000
| Max Bed Clearance | 90 inches |
| Weight | 1386 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 26′-36′ |
Hydraulic Turntable Functions
- Post lifts up for 7.5 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
HDRTH-6000
| Max Bed Clearance | 90 inches |
| Weight | 1595 lbs. |
| Minimum Loading Height | 30 inches |
| Conveyor lengths | 38′-41′ |
Hydraulic Turntable Functions
- Post lifts up for 7.5 foot load clearance and lowers down to 30″ for conveyor loading
- Conveyor boom inclines up to 70 degrees
- Forward and Reverse belt operation
- 360 degree conveyor boom rotation
